About Pipedata

Pipedata has dimensional and weight information for 72 common ASME piping components all in a fast, convenient and easy to use interface. The Pipedata name has been around since 1996, when it was first applied to Pipedata-Pro. Since then it's gained a global presence in the piping industry with large corporations and individuals appreciating the Pipedata hallmarks of accuracy and up-to date relevant information.

Based on the latest ASME piping dimensional specifications it shows Metric, U.S. Customary Units and Inch Fractions, NPS and DN pipe sizes and includes audited valve weights, flange weights, pipe weights and all piping component weights.

DATA SUMMARY
Pipe ASME B36.10M/19M - 2004
WeldNeck Flange, ASME B16.5-2013
Slip On Flange, ASME B16.5-2013
Blind Flange, ASME B16.5-2013
Threaded Flange, ASME B16.5-2013
SocketWelded Flange, ASME B16.5-2013
Lapped Flange, ASME B16.5-2013
Long Welding Neck Flange, ASME B16.5-2013
Buttwelded 45deg Elbow, ASME B16.9-2007
Buttwelded 90deg Long Radius Elbow, ASME B16.9-2007
Buttwelded 180deg Long Radius Return, ASME B16.9-2007
Buttwelded 90deg Short Radius Elbow, ASME B16.9-2007
Buttwelded 180deg Short Radius Return, ASME B16.9-2007
Buttwelded Equal Tee, ASME B16.9-2007
Buttwelded Reducing Tee, ASME B16.9-2007
Buttwelded Cap, ASME B16.9-2007
Buttwelded Concentric Reducer, ASME B16.9-2007
Buttwelded Eccentric Reducer, ASME B16.9-2007
Buttwelded Lap Joint Stub End, ASME B16.9-2007
Threaded 90deg Elbow, ASME B16.11-2011
Threaded Tee, ASME B16.11-2011
Threaded Cross, ASME B16.11-2011
Threaded 45deg Elbow, ASME B16.11-2011
Threaded 90deg Street Elbow, ASME B16.11-2011
Threaded Coupling, ASME B16.11-2011
Threaded Half Coupling, ASME B16.11-2011
Threaded Cap, ASME B16.11-2011
Threaded Square Head Plug, ASME B16.11-2011
Threaded Hex Head Plug, ASME B16.11-2011
Threaded Round Head Plug, ASME B16.11-2011
Threaded Hex Head Bushing, ASME B16.11-2011
Threaded Flush Bushing, ASME B16.11-2011
Socketwelded 90deg Deg Elbow, ASME B16.11-2011
Socketwelded 45deg deg Elbow, ASME B16.11-2011
Socketwelded Tee, ASME B16.11-2011
Socketwelded Cross, ASME B16.11-2011
Socketwelded Coupling, ASME B16.11-2011
Socketwelded Half Coupling, ASME B16.11-2011
Socketwelded Cap, ASME B16.11-2011
Socketwelded Reducing Coupling, ASME Unadopted
Socketwelded Welding Boss, ASME Unadopted
Socketwelded Reducing Insert Type 1, ASME Unadopted
Socketwelded Reducing Insert Type 2, ASME Unadopted
Socketwelded Reducing Insert Type 3, ASME Unadopted
Socketwelded Union, ASME Unadopted
Socket Details, ASME B16.11-2011
Non Metallic Flat Ring for ASME B16.5 Flanges, ASME B16.21-2011
Non Metallic Flat Ring for ASME B16.47 Series A Flanges, ASME B16.21-2011
Non Metallic Flat Ring for ASME B16.47 Series B Flanges, ASME B16.21-2011
Spiral wound for ASME B16.5 Flanges, ASME B16.20-2012
Spiral wound for ASME B16.47 Series A Flanges, ASME B16.20-2012
Spiral wound for ASME B16.47 Series B Flanges, ASME B16.20-2012
RTJ Soft Iron Ring type R, ASME B16.20-2012
RTJ Soft Iron Ring RX, ASME B16.20-2012
RTJ Soft Iron Ring BX, ASME B16.20-2012
Flanged Gate Valve, ASME B16.10-2009
Flanged Globe Valve, ASME B16.10-2009
Flanged Ball Valve, ASME B16.10-2009
Flanged Control Valve, ASME B16.10-2009
Flanged Swing Check Valve, ASME B16.10-2009
Flanged Wafer Check Valve, API 594
Wafer type Butterfly Valves, ASME B16.10-2009
Lug type Butterfly Valves, ASME B16.10-2009
ButtWelded Gate Valve, ASME B16.10-2009...
- and much more, Check it out

Frequently Asked Questions(FAQ)

What is Pipedata?

Pipedata is a software that provides dimensional and weight information for common ASME piping components in a user-friendly interface.

How long has Pipedata been around?

The Pipedata name has been around since 1996 when it was first applied to Pipedata-Pro.

What types of information does Pipedata provide?

Pipedata provides Metric, U.S. Customary Units, Inch Fractions, NPS and DN pipe sizes, as well as audited valve weights, flange weights, pipe weights, and all piping component weights.

Is Pipedata based on the latest ASME piping specifications?

Yes, Pipedata is based on the latest ASME piping dimensional specifications.

Who uses Pipedata?

Pipedata is used by large corporations and individuals in the piping industry who appreciate its accuracy and up-to-date relevant information.

What are some examples of piping components included in Pipedata?

Examples of piping components included in Pipedata are weldneck flanges, slip-on flanges, blind flanges, threaded flanges, socketwelded flanges, and many more.

Does Pipedata cover non-metallic and spiral wound components?

Yes, Pipedata includes information on non-metallic flat rings and spiral wound gaskets for various flange types.

Does Pipedata include information on valves?

Yes, Pipedata includes information on various types of valves such as gate valves, globe valves, ball valves, control valves, swing check valves, wafer check valves, butterfly valves, and more.

Can I find information on butt-welded gate valves in Pipedata?

Yes, Pipedata includes information on butt-welded gate valves.

Can I find information on wafer type butterfly valves in Pipedata?

Yes, Pipedata includes information on wafer type butterfly valves.
