Simurelay

Описание Simurelay

Simurelay is an Android App to help you draw and simulate electrical classic control.
Breakers and Switch fuse which used in this app behave just like simple contacts.
Available elements :
- Neutral N
- Power supply L1
- Power supply L2
- Power supply L3
- Power supply L1L2L3
- Power supply L1L2L3N
- 3 Phase generator
- Phase sequence
- Coil relay
- Coil contactor
- Impulse relay
- On delay relay (only Premium)
- Off delay relay (only Premium)
- On/Off delay relay (only Premium)
- Flasher relay (only Premium)
- Contact NO
- Contact NC
- Contact COM NC NO
- Contact NC NO
- Push button NO
- Push button NC
- Push button COM NC NO
- Push button NC NO
- Switch NO
- Switch NC
- Switch COM NC NO
- Switch NC NO
- Switch 3 positions I_O_II
- Switch 3 positions I_II_III
- Emergency NO
- Emergency NC
- Emergency COM NC NO
- Emergency NC NO
- Limit switch NO
- Limit switch NC
- Limit switch COM NC NO
- Limit switch NC NO
- Contactor 2 pole
- Contactor 3 pole
- Contactor 4 pole
- Isolator 1 pole
- Isolator 2 pole
- Isolator 3 pole
- Isolator 4 pole
- Circuit breaker 1 pole
- Circuit breaker 2 pole
- Circuit breaker 3 pole
- Circuit breaker 4 pole
- Switch fuse 1 pole
- Switch fuse 2 pole
- Switch fuse 3 pole
- Switch fuse 4 pole
- Magneto circuit breaker 2 pole
- Magneto circuit breaker 3 pole
- Thermal overload relay 2 pole
- Thermal overload relay 3 pole
- Motor three phase
- Motor three phase 6 pole
- Motor single phase
- Lamp
- Flashing lamp
