Annitori QS PRO 3 Quickshifter

1) Make sure your Bluetooth is turned on on your Android Device.
2) With the app closed, start your motorcycle. This is very important, you must start your machine BEFORE you open the app, so that the BT on the shifter is searching as you open the Annitori App to connect.
3) After the bike is started, open the app and click "SCAN" at the top so the app will begin searching for the shifter.
4) If a QS Pro shifter is on and in range you will see a list appear on screen.
5) Click on the "QS PRO" to connect the app to the shifter.
6) When the app has connected with the shifter it will show the settings screen.
7) When connected AND reading, you will see the settings of what is in your shifter.
8) Note that when the read is correct and actual, you will see the Firmware line will show a version number, and the RPM, Sensitivity and Kill Time will all have realistic values. Now you know you are connected. If you do not see these, you are NOT reading the shifter and need to start the process over again.
9) If ever in doubt, simply exit the app and start over, this whole process takes 10 seconds. In fact, we STRONGLY recommend that after any settings change or use of the app, when done, EXIT the app completely. This way you know you are out, and can only come back in from the start. If ever in need of help, contact us, always happy to assist you!
10) You are now ready to make changes to your QS PRO settings
11) NOTE: REX should be at 18, and always left at 18 unless you are having problems and have been in contact with our Customer Service directly. They will instruct you to make any changes, otherwise leave RFX at 18 and never change it.
12) As you can see, making changes are now very simple to do!
a) RPM (choose your desired value)
b) PUSH (right to enable, left to disable)
c) PULL (Switch right to enable, left to disable)
d) Kill time - touch the number and a spinner will come up with all the kill time values in milliseconds. Choose the kill time you wish to enter.
d) Sensitivity - touch the number and a spinner will come up with the options. A sensitivity of 10 means more pressure to activate the kill signal, 80 means very light.
13) When you have your choices made, click SAVE and make sure you have successfully written to the shifter
As always, if you have any questions please contact us...!
